LX-B Series Vertical Autoclave
NS
Full SUS 304 stainless steel structure
Accurate dual scale indicate pressure gauge
Silicone seal ensuring no steam leakage
Spin buttons to set sterilization temperature and time
Blue, orange and red light showing work status
Automatic release when overpressure
Water shortage and over heating protection
Drying function can be added
TECHNICAL DATA MODEL | LX-B35L | LX-B50L | LX-B75L | LX-B100L | LX-B120L | LX-B150L |
Volume | 35L | 50L | 75L | 100L | 120L | 150L |
Max Working Pressure | 0.165Mpa | 0.165Mpa | 0.165Mpa | 0.165Mpa | 0.165Mpa | 0.165Mpa |
Time Range | 0-80min | 0-80min | 0-80min | 0-80min | 0-80min | 0-80min |
Temperature Range | 115℃-129℃ | 115℃-129℃ | 115℃-129℃ | 115℃-129℃ | 115℃-129℃ | 115℃-129℃ |
Sterilization Chamber | Φ300*485mm | Φ320*545mm | Φ388*480mm | Φ388*630mm | Φ460*590mm | Φ460*700mm |
Power | AC220V/50Hz/ 2.5KW | AC220V/50Hz/ 2.5KW | AC220V/50Hz/ 3.5KW | AC220V/50Hz/ 4.0KW | AC220V/50Hz/ 4.0KW | AC220V/50Hz/ 4.0KW |
